※このページの画像等の大半は当方所有の無線機類ですが、少しでも多くの方に沢山の機種を知ってもらう為に 軍用無線機ファンの方からの画像や情報をお待ちしております。

BC-224 200-500KHz & 1.5-18.1MHz,VFO
BC-322 52-66MHz,AM,100mW,VFO
BC-312-N 1.5-18MHz,AM/CW,VFO PIC
BC-314 150-1500KHz,AM/CW,VFO PIC
BC-348-L 200-500KHz/1.5-18MHz,AM/CW,VFO PIC
BC-610 1.5-18MHz,AM/CW,400W
BC-611 3.5-6MHz,AM,0.050W, XTAL
BC-653 100-400KHz & 1.5-6MHz,AM/CW,50W,VFO
BC-659 27-38.9MHz,FM,2ch,XTAL
BC-745 2-6MHz,AM,750mW,XTAL
BC-1000 40-48MHz,FM,300mW,VFO PIC
BC-1306 3.8-6.5MHz,7/15W
BC-1335 27-38.9MHz,FM,2ch,XTAL PIC
TCS-11 1-12MHz,AM/CW PIC
R-19/TRC-1 70-100MHz,FM PIC

AN/ARC-73   PIC
AN/PRC-6 47-55.4MHz,FM,250mW,XTAL PIC
PRC-6/6(ドイツ) 47-55.4MHz,FM,6CH,250mW,1.5/45/90/-4.5V PIC
KPRC-6A(韓国) 27-30MHz,FM,2CH,500mW,12V PIC
AN/PRC-8(A) 20-27.9MHz,FM,1.2W,VFO
AN/PRC-9(A) 27-38.9MHz,FM,1W,VFO PIC
AN/PRC-10(A) 47-58.4MHz,FM,500mW,VFO PIC
AM-598/VRC Amplifier-power supply, 24 VDC input, part of AN/PRC-8, AN/PRC-9
and AN/PRC-10
PIC
AN/PRC-14 225-400MHz,AM,1W,XTAL
AN/PRC-17A 121.5/243MHz,AM/MCW,50mW,XTAL
AN/PRC-21 152-174MHz,FM,150mW,XTAL PIC
AN/PRC-25 30-75.95MHz,FM,1-1.5W,SYN PIC
AN/PRC-35 VHF/Low FM PIC
AN/PRC-47 2-12MHz,USB/VOICE/CW,20/100W,SYN PIC
AN/PRC-49(A,B,C) 243MHz,AM/MCW,100mW,XTAL
AN/PRC-55 VHF/Hi FM PIC
AN/PRC-62 2-30MHz,AM/CW/SSB/MCW,20W
AN/PRC-63 243MHz,AM/MCW,325mW,XTAL
AN/PRC-64 2.5-6 MHz,CW,4ch,5W PIC
AN/PRC-66(A,B) 225-400MHz,AM,2W,SYN
AN/PRC-68 30-80MHz,FM,1W,SYN PIC
AN/PRC-68A 30-80MHz,FM,2W,SYN PIC
AN/PRC-68B 30-80MHz,FM,25KHz STEP,SYN PIC
AN/PRC-70 2-30,30-76MHz,USB/LSB/CW/FM,3/20-40W,SYN PIC
AN/PRC-71 HF/SSB,VHF/Low FM,VHF/Air,UHF/Air. PIC
AN/PRC-72 VHF/Low FM,UHF/Air,etc PIC
AN/PRC-73 132-174MHz,FM,1.5W,XTAL
AN/PRC-74A 2-12MHz,USB/VOICE/CW,15W,SYN PIC
AN/PRC-74B,C 2-18MHz,USB/VOICE/CW,15W,SYN
AN/PRC-75(A,B) 225-400MHz,AM1W,SYN PIC
AN/PRC-77 30-75.95MHz,FM,1.5-2W,SYN PIC
AN/PRC-88 20-80MHz,FM,2400ch,3W PIC
AN/PRC-90 243 and 282.8MHz,AM,200mW PIC
AN/PRC-91A 132-150.8MHz,FM
AN/PRC-96 121.5-243MHz,AM,XTAL
AN/PRC-103 243 and 282.8MHz,AM,200mW,water rescue
AN/PRC-104(A,B) 2-30MHz,AM/SSB/CW,20W,SYN PIC
AN/PRC-112 UHF 225-299.975MHz(243 and 282MHz),UHF 1W, VHF 100mW PIC
AN/PRC-113(V)(3,A,B) 116-150,225-400MHz,AM,2/10W,SYN PIC
AN/PRC-117 30-90MHz,FM,1-10W,SYN PIC
AN/PRC-119 30-87.975MHz,FM,0.4-4W,SYN PIC
AN/PRC-126 30-88,FM,1W,SYN PIC
AN/PRC-127 136-160MHz,FM,2.5/5KHz STEP,2W,12V(?),SYN PIC
AN/PRC-128 30-88 or 130-174MHz, depending on module installed,FM,SYN PIC
AN/PRC-136 130-174MHz,FM,SYN
AN/PRC-138 1.6-30MHz,SSB/FM,20W(SSB)/10W(FM),SYN
AN/PRC-139 30-88,136-174,403-470MHz,FM,0.5/2W,SYN
AN/PRC-515 2-30MHz,SSB/AM/CW,20W,SYN
AN/PRC-521 30-87.9875MHz,FM,0.5/2W,SYN
PRC-1077 30-87.975MHz,FM,25KHz STEP,0.1/1.5/5W,14V(?),SYN PIC
PRC-1088 ,SYN PIC
PRC-1099 20W,SYN PIC
PRC-6725E 30-88/136-174/403-470 MHz,0.5 and 2 Wat,SYN
AN/PRT-4 & PRR-9 47-57MHz,FM,0.15W,XTAL PIC
AN/URT-33 243MHz beacon PIC
HST-4A 225-399.995MHz,Low 3.5W, High 15W-28W,AM,FM,FSK,SBPSK PIC

RT-60 240-260 and 270-290MHz (normally set for 243.0 and 282.8MHz), AM PIC
RT-68/GRC 47-58.4MHz,FM,VFO PIC
RT-70/GRC 47-58.4MHz,FM,500mW,VFO PIC
RT-524 30-74.95MHz,FM,8W/35W,SYN PIC
RT-662/GRC 2-30MHz,SSB/CW,100mW(CW),400mW[PEP](SSB) PIC
RT-834/GRC RT834 (GRC-106A)2-30MHZ,AM,CW,FSK,USB,100Hz step,100mW,28V PIC
RT-1512/GRC RT-1512(GRC-215)2-29.9999MHZ,LSB,USB,DATA,CW,100mW PIC
RT-9000 1.6-29.999MHZ,AM,CW,USB,LSB,125/65W PIC
R-108/GRC 20-28MHz, FM
R-109/GRC 27-39MHz, FM PIC
R-110/GRC 38-54MHz, FM PIC
R-274/FRR 0.54-54MHz,AM/CW PIC
R-390/URR 0.5-32MHz,AM/CW
R-390A/URR 0.5-32MHz,AM/CW PIC
R-392/URR 0.5-32MHz,AM/CW PIC
R-442/VRC 30MHz-76MHz, 920chan, 24 VDC PIC
R-744B/URR 20-100MHz, AM/CW/FM PIC
R-1518/URR 20-150MHz,2BAND, AM/CW/FM PIC
AN/GRC-7 Radio set,38-54.9MHz,FM,Vehicular,Major component: RT-68, RT-70,AM-65,R-110, PP-112 and PP-282 PIC
AN/GRC-9 2-12MHz AM/CW,3.5-15W PIC
AN/GRC-109 3-22MHz CW TX,3-24 MHz AM/CW PIC
AN/GRC-213 2-30MHz,AM/SSB/CW,20W,SYN PIC
AN/GRC-236CV 30-88MHz/136-174MHz/403-470MHz,3BAND,LOW 4W/MID 15W/HI 40W, PIC
AN/GRR-5 1.5-18MHz,AM/SSB/CW PIC
AN/TRC-176 Same as PRC113 except following items PIC
AN/URC-101 116-150MHz and 225-400Mz,1.5, 5, or 20W AM/FM. PIC
AN/URC-104 30-88 and 225-400MHz, AM (UHF)/FM (VHF/UHF). PIC
AN/URR-44 540KHz〜18.6MHz、4BAND(R892) PIC
URC-773 36-75.975MHz, FM,1/4.5W,9-18V, PIC
AN/VRC-10 Radio set,38-54.9MHz,FM,Vehicular,Major component: RT-68, C-375 and PP-112, TM 11-286. PIC
AN/VRC-94(V) 30-89.975MHz 1/10W(0.1w OP) FM/FH PIC
SP-600 ハマーランドSP-600 PIC
TRA-967(RACAL) 36-75.975MHZ,FM,25KHz STEP,5W,12V PIC
SEM 25(ドイツ) 26-70MHz,FM,50KHzSTEP,1/15W,28V PIC
SEM 35(ドイツ) 26-70MHz,FM,50KHzSTEP,0.15/1W,12/24V PIC
SEM 52-A(ドイツ) 47-56.95MHz,FM,6CH,300mW,9V PIC
RBO-3 0.53〜1.6MHz & 5.55〜15.6MHz PIC
PRM4090 20-79.975MHz,FM (Narrow band FM),Low 10mW, High 5W PIC
TR-PP-11B1(フランス) 47-57,FM,6CH,500mW,15V PIC
CPRC-26(カナダ) CPRC-26,47-55.4MHz,FM, 6CH,250mW,1.5/45/90/-3V PIC
JAGUER V 30-88MHz 10mW/5W/20W Manpack時DC-12V PIC
GRR-17 2-30MHz DC24V/AC110V USB.LSB.CW.AM. PIC

94式5型受信機 旧日本軍受信機 PIC
JAN/GRC-N1 自衛隊地上無線機 HF帯SSBトランシーバー PIC
NRT-45/VRC-4A VHF 2ch 150MHz帯 空自 DC-12/24V PIC
KY-38 米軍秘話装置 PIC
GRR-N4(GR-N7/URR) 受信機 1.5-12MHz LSB/USB/CW.AM 単一6本  PIC
JRT-F3 陸上自衛隊 無線機 PIC
JFR-N7 陸上自衛隊 周波数計 JFR-N7,JFR-N14,JFR-N28B PIC
AN/USM-207B DIGITAL READOUT ELECTRONIC COUNTER PIC
自衛隊受信機 日本電気製自衛隊受信機 HF帯 PIC
自衛隊受信機 アンリツ製自衛隊受信機 HF帯 PIC
RRT-2 防衛庁 送信機 PIC
自衛隊受信機(ラジオ) 530-1605KHz,AM,VFO PIC
中国軍139A受信機 1.5-18MHz,VFO PIC
中国軍 魯−3452A無線機 VFO PIC
JRC NRD-1051CS   PIC
5R-10A 540KHz-32MHz,4BAND PIC
5R-100A 540KHz-32MHz,4BAND PIC
S-38 540KHz-32MHz,4BAND PIC
S-38D 540KHz-32MHz,4BAND PIC
S-40B 540KHz-44MHz,4BAND PIC
S-41G 550KHz-30MHz,4BAND PIC
S-107 550KHz-54MHz,5BAND PIC
S-120 550KHz-30MHz,4BAND PIC
SW-54 540KHz-30MHz,4BAND PIC
SX-43 538KHz-34MHz PIC
SX-99 538KHz-34MHz,4BAND PIC
SX-110 538KHz-34MHz,4BAND PIC
HQ-100 540KHz-30MHz PIC
NC-57 540KHz-54MHz,5BAND PIC
WJ-8736-6 20MHz-500MHz,CW/AM/FM PIC
KNM-402C & KNM-502 300Hz-30MHz,6BAND & 25MHz-500MHz,8BAND PIC
RV-8S & RP-108 280Hz-28MHz,A1/A3/A3H/A3J,PLL PIC
9R-59 150KHz-30MHz PIC
KT-320 150KHz-30MHz PIC
DX-160 150KHz-30MHz PIC
SR-100 55KHz-160KHz,3.5MHz-10MHz,2BAND PIC
DX-200 155KHz-30MHz,5BAND AM/LSB/USB/CW PIC
GR-64 550KHz-30MHz,5BAND AM/RTTY/CW PIC
AX700B 50MHz-905MHz,AM,FMN,FMW PIC

昔懐かしのアマチュア無線機 USA製 真空管式トランシーバー 昔懐かし合法CB無線機
懐かしの軍用風テレビ? SONY SPORTS 7 & 11 おもちゃのトランシーバー

MUSEN HEYA
MUSEN HEYA

当方の軍用無線機部屋の一辺
